Free Wavetable

CC0 1.0 Universal (CC0 1.0) Public Domain Dedication

Free Wavetables was created using resampling and numerical calculations. Some of wavetables have been converted and uploaded from WaveEdit Online.
They can be used with most Wavetable synthesizers that can import Wav files.

New Wavetables will be added. If you would like to receive updates, subscribe to Mailing List.

To reduce the file size, the files are compressed in 7z format. Download the 7z compatible software from the link below.
*MacOS can also decompress the 7z format with the default software, but it will corrupt the files.

7z unzip software

7-Zip	Windows
The Unarchiver	Mac
Keka	Mac
p7zip	Linux

Wavetable

Format

2048samples-32bit-44.1kHz-Wav
1024samples-16bit-44.1kHz-Wav
512samples-16bit-44.1kHz-Wav
256samples-16bit-44.1kHz-Wav
128samples-16bit-44.1kHz-Wav

Batch Download Links

All formats including Wavetables and single cycle waveforms	Compatible synths
Only wavetables[128samples]	Blofeld, Micromonsta mk1,
Only wavetables[256samples]	*Blofeld, E352, E370, Piston Honda MK3,Chord V2
Only wavetables[512samples]	4ms SWM, Polyend Tracker
Only wavetables[1024samples]	Ableton Wavetable, *Pro3, Polyend Tracker
Only wavetables[2048samples]	Almost all plug-in wavetable synths

* These synths have to be converted into SysEx files using special software. For more information, read Tools for importing into hardware synths below!.

Single cycle waveform + Chord tuned to NoteC

Download

Format

48kHz-16bit-Wav-[Analog Rytm, Digitakt, Model:Samples]
44.1kHz-16bit-Wav- [Octatrack]

How to convert wavetable to note C length for samplers

Single cycle waveforms tuned to Note C

Single cycle waveforms tuned to NoteC were converted from Single cycle wavfomrs of some Free wavebles to Note C lengths. By looping the waveforms, you can use the sampler as a synth. It is also the third oscillator in Analog rytm's Dual VCO.

Single cycle chords

Cycle chords are waveforms made by additive synthesis based on single cycle waveforms. You can easily create chord stub sounds by combining filters and effects.

Tone2 Icarus Spectrum Editor

Waveform Generators

User Wavetable Creation Tools
Single Cycle Waveform Creation Tools
Tutrials on Creating and Converting Wavetables

Vital(Create waveforms with 2048 samples per frame)
WaveEdit(Create waveforms with 256 samples per frame)
SphereEdit(Create waveforms with 512 samples per frame)
WaveEdit for Sequential Pro 3(Create waveforms with1024 samples per frame)
AudioTerm [For Windows]

Scripts for Octave to create Wavetables

Tools for importing into hardware synths

Waldorf Blofeld
Sequential PRO3
Korg MinilogueXD/Prologue
MicroMonsta MK1
Elektron Monomachine

[Supported Wavetable format] 64 × 128samples or 32 × 256samples

blofeld_wavetable_creator_[For Windows Users]
wave2blofeld for Mac(This tool converts Wav files to Syx files for blofeld.)
Bigglesworth(This tool is blofeld’s editor, but seems to have feature to load Wav files directly.)It is freeware, but please donate it for development.
ToneTweak Blofeld Editor(This tool is blofeld’s editor, but seems to have feature to load Wav files directly.)
AudioTerm [For Windows]

[Supported Wavetable format] 16 × 1024 samples 16 bit-48 kHz
