Free Wavetable

CC0 1.0 Universal (CC0 1.0) Public Domain Dedication

Download

Free Wavetables were created by programming and resampling, and include Wavetables resampled from WaveEdit. They are in the public domain and can be used freely.
They can be used with most Wavetable synthesizers that can import Wav files.

Content List

Update(08/09/2021)

---

Format	Compatible synths
2048samples per one frame-32bit-44.1kHz-Wav	Most plug-in wavetable synths(Serum,Vital, Icarus2,SynthMaster.........)
1024samples per one frame-16bit-44.1kHz-Wav	Ableton Wavetable, Polyend Tracker, Pro3
512samples per one frame-16bit-44.1kHz-Wav	4ms SWM, Polyend Tracker
256samples per one frame-16bit-44.1kHz-Wav	*Blofeld, Synthesis Technology WaveEdit, Piston Honda MK3, Chord V2
128samples per one frame-16bit-44.1kHz-Wav	*Blofeld, *Micromonsta MK1

 * These synths have to be converted into SysEx files using special software. For more information, read Tools for importing into hardware synths below!.

---

Waveform Generators

• User Wavetable Creation Tools
• Single Cycle Waveform Creation Tools
• Tutrials on Creating and Converting Wavetables


<

>

• Vital(Create waveforms with 2048 samples per frame)

• WaveEdit(Create waveforms with 256 samples per frame)
• SphereEdit(Create waveforms with 512 samples per frame)
• WaveEdit for Sequential Pro 3(Create waveforms with1024 samples per frame)
• AudioTerm [For Windows]

• Waveform Generation
• Hard/Softcore by Ess Mattisson
• WaveEdit
• The SCW Editor
• Selection Shaper(Renoise Tool)


Scripts for Octave to create Wavetables

• The basics of creating Wavetables vol.1
• The basics of creating Wavetables vol.2
• The basics of creating Wavetables vol.3[FM synth]
• The basics of creating  wavetables vol.4[Envelope]

• How to change the length of Wavetables
• How to convert Abelton Operator waveforms to Wavetables

---

Tools for importing into hardware synths

• Waldorf Blofeld

• Sequential PRO3
• Korg MinilogueXD/Prologue
• MicroMonsta MK1
• Elektron Monomachine

<

>

[Supported Wavetable format] 64 × 128samples or 32 × 256samples

• blofeld_wavetable_creator_[For Windows Users]
• wave2blofeld for Mac(This tool converts Wav files to Syx files for blofeld.)
• Bigglesworth(This tool is blofeld’s editor, but seems to have feature to load Wav files directly.)It is freeware, but please donate it for development.
• ToneTweak Blofeld Editor(This tool is blofeld’s editor, but seems to have feature to load Wav files directly.)
• AudioTerm [For Windows]

[Supported Wavetable format] 16 × 1024 samples 16 bit-48 kHz

• PRO3 Wavetable Generator
• WaveEdit for Sequential Pro 3 (Wavetable creation tool for Pro3)

Script for Octave/Matlab
As most Wavetables are 44.1kHz files, here is a script for Octave/Mtalab that allows bulk conversion to 48kHz.

Script for batch conversion of files to 48kHz sampling frequency

[Supported Wavetable format] 64 × 256samples-8bit-44.1kHz

• wavDesk: Wavetable Loader for Minilogue XD/Prologue by Roll-log Sounds

Discontinued Product

[Supported Wavetable format] 33 × 128samples-16bit-44.1kHz

• micromonsta wavetable helper tool
• WaveEdit for Micromonsta (Wavetable creation tool for micromonsta)

Discontinued Product

C6 is not supported by the current Mac OS.

• C6 SysEx Manager
